InSight™ Firmware Version 6.0

625

PN: 2002881 Rev.F

C

OTTON

T

ROUBLESHOOTING

T

ABLE

Problem

Possible Cause

Solution

Module LED light is
flashing red.

Module does not
have firmware
properly installed.

Reload firmware to the module through the
Upgrade button. To reload firmware to the
module, follow the same process as used when
upgrading firmware to the InSight monitor.

Module LED light is
solid red.

Possible module
failure.

Contact Ag Leader Technical Support.

Module LED light is
flashing orange.

Power is being
supplied to the
module, but there is
no CAN bus
communication.

Check the CAN bus cables for bent or broken pins
at each connection. If you can see no physical cable
problem, contact Ag Leader Technical Support.

Module LED light is
not lit up.

The module is not
receiving power.

Check cables for disconnections, breaks or cuts in
the line.

The InSight monitor
is displaying a low
signal strength
warning.

Dirt or debris is
covering the lenses
on the emitter or
detector.

Once per week, wipe the lenses clean to ensure the
best performance.

Sap from cotton is
smeared on lenses.

If defoliation is not complete before harvest
begins, sap from cotton plants may build up on the
lenses. To ensure accuracy, you may need to clean
the lenses with a non-ammonia based cleaner.

Sensors are not
properly aligned.

Check the alignment of the sensors by slightly
moving the emitter to see if signal strength
increases. As precise movements are needed, move
the emitter slowly and slightly.

The InSight monitor
is displaying
inaccurate yields
(John Deere pickers
only).

The ground strap is
not installed
properly.

John Deere pickers need ground straps installed on
their flow sensors to remove static buildup. Make
sure this ground strap is properly installed on the
picker and is also properly grounded. Check the
installation instructions for proper placement of
the cable.
