InSight™ Firmware Version 6.0
585
PN: 2002881 Rev.F
P
ICKER
T
AB
B
UTTONS
(
CONTINUED
)
Button Description
The Sensor Settings button opens the Sensor Settings window, where you can
edit the Low Signal Alarm and Zero Flow Threshold. For more information, see
“Sensor Settings” on page 588 .
The GPS Offsets button allows you to specify the location of the GPS antenna
in relation to the vehicle. A wizard will walk you through these edits. For more
information, see
“GPS Offsets” on page 589 .
The Calibrate Distance button calibrates the radar, track or wheel speed
sensor. For more information, see
“Calibrate Distance” on page 590 .
The Calibrate Header Sensor button launches the Header Sensor Calibration
Wizard, which will walk you through calibrating the header sensor that turns
area logging on and off. For more information, see
“Calibrating The Header
Sensor” on page 592 .
