Ag Leader InSight Cotton Harvest Insert Ver.6.0 Users Manual User Manual
Page 35

InSight™ Firmware Version 6.0
607
PN: 2002881 Rev.F
A
DDING
A
N
EW
C
ALIBRATION
(C
ONTINUED
)
Step 5: New Calibration Appears
The new calibration now appears on the
Calibration drop-down menu. The calibration's
date of creation appears to the right of the
name.
• If the drop-down menu doesn’t appear, no
data has been previously logged.
• If no loads appear in the Cotton Weight
Calibration portion of this window, it is because
you have not checked loads specifically as
calibration loads.
All regions that have been marked as
cal loads will show only for the current
calibration.
Step 6: Perform new Weight Calibration
After you have created a new calibration, it is
recommended that you perform another weight
calibration. Refer to the procedure described in
“Entering Actual Load Weights” on page 603.
When you perform a weight calibration
on a second calibration, the data from the
first calibration is not affected.
