InSight™ Firmware Version 6.0
601
PN: 2002881 Rev.F
F
IELD
A
REA
C
ALIBRATION
To access the Area Calibration window, press the Field Area Calibration button. From here, you can
modify the field area that you have logged. To perform a Field Area Calibration, select the field that you
wish to calibrate and then press the numeric keypad button. Enter in the correct area and press Accept.
Area Calibration: Cotton window
Settings Description
The Field drop-down list shows all fields available for an area
calibration.
Inside the Area Adjustment section of the window, the Actual
Area numeric keypad allows you to enter a known field area,
shown in acres.
The Area Calibration section of the window shows the
percentage of measured area as a part of the user-entered
area. This percentage value will change if you change the Area
Adjustment.
