Table 9 XP24000

1AU/2MU

1AL/2ML

DKA Set 1

DKA AU=0 , AL=1,

DKA MU=8, ML=9

1BU/2NU

1BL/2NL

DKA Set 2

DKA BU=2, BL=3

DKA NU=10,NL=11

1LU/2XU

1LL/2XL

DKA Set 3

DKA LU=4, LL=5

DKA XU=12,XL=13

1KU/2WU

1KL/2WL

DKA Set 4

DKA KU=6, KL=7

DKA WU=14,WL=15

1EU, 2QU

1EL, 2QL

CHA Pair 1

CHA EU=0, EL=1

CHA QU=8,QL=9

1FU,2 RU

1FL,2 RL

CHA Pair 2

CHA FU=2,FL=3

CHA RU=10,RL=11

1GU, 2TU

1GL, 2TL

CHA Pair 3

CHA GU=4,GL=5

CHA TU=12,TL=13

1HU,2UU

1HL,2UL

CHA Pair 4

CHA HU=6,HL=7

CHA UU=14,UL=15

1AU,2MU

1AL,2ML

CHA Pair 5

CHA AU=16,AL=17

CHA MU=24,ML=25

1BU, 2NU

1BL, 2NL

CHA Pair 6

CHA BU=18,BL=19

CHA NU=26,NL=27

1LU, 2XU

1LL, 2XL

CHA Pair 7

CHA LU=20,LL=21

CHA XU=28,XL=29

1KU,2 WU

1KL,2 WL

CHA Pair 8

CHA KU=22,KL=23

CHA WU=30,WL=31

NOTE:

The numbers in the third column correspond to the card letter. These numbers are used when reading

CLUI output that has an older formatting style.

Table 10

lists the ACP and CHIP pairs for XP20000.

Table 10 XP20000

1A/2F

ACP Pair1

DKA 1A =0, DKA 2F=8

1B/2E

ACP Pair 2

DKA 1B=2, DKA 2E=10

1G/2L

CHIP Pair 1

CHA 1G=0, CHA 2L=8

1H/2K

CHIP Pair 2

CHA 1H=2, CHA 2K=10

1A/2F

CHIP Pair 3

CHA 1A=16, CHA 2F=24

1B/2E

CHIP Pair 4

CHA 1B= 18, CHA 2E=26

Viewing and sorting data

Each table column in the Grid Display screen can be resized to a different width. A scroll bar appears at

the bottom of the table if more data is available than can be seen in a single screen.

32

Grid Display
