Table 28 Chart Screen Selections for XP10000/XP12000/XP24000/XP20000

Cache Partition charts

Array/Group

Metric Category

Metric

Resource List Title Resource List

Contents

Any disk array

model or serial

number

MB Metrics or

Utilization Metrics

Cache Usage

Cache Partition

All

An XP 12000

serial number

MB Metrics or

Utilization Metrics

Cache Write

Pending or Cache

Sidefile Usage

Cache Partition

All, 0, 1, 2, 3, ...

A non-XP 12000

serial number

MB Metrics or

Utilization Metrics

Cache Write

Pending or Cache

Sidefile Usage

Cache Partition

All

A custom group

name

MB Metrics or

Utilization Metrics

Cache Usage,

Cache Write

Pending, or Cache

Sidefile Usage

Cache Partition

Empty

NOTE:

The chart may show the utilization as zero for invalid MPs. This is because the mix CHIPs

and mix ACPs have only four MPs each. For example, if you select Utilization Metrics,

from the metric category combo box in the Chart screen for an XP10000, and then select

utilization for MP 4, MP 5, MP 6, MP 7 for mix ACP Pairs, mix ACPs or mix CHIPs from

the Metric combo box, the resultant chart displays zero utilization for those MPs because

the MPs are invalid for mix PCBS.
Chart will not display the utilization metrics for concatenated ACP pairs.

TIP:

The individual CHIP utilization metric displays the average utilization of each MP in the

CHIP, the CHIP utilization per MP displays the utilization for each MP in the CHIP, and the

overall CHIP utilization chart displays the average utilization of each MP in the array.

Working with groups

You can also create and chart groups of specific host and array components by creating a group in

the PA XP Group Configuration screen on the Configuration tab. The Group Configuration screen is

a configurable Grid Display screen.
After you select the parameters for your group, the system returns the results of your selections. For

example, the system can add all the total IOs for invalid ACP Pairs, or it can add the LDEVs for a custom

RAID group. Ensure that you have selected every element that you want to appear in the chart, because

the system can chart only those elements that are specified. After you create a group in the Groups screen,

the new group automatically appears in the Array/Group drop-down menu in the Charts screen. Use the

Metric Category and Metric drop-down menus to select the metrics that you want to chart for your group.
