GSP-730 User Manual

80

Panel operation

1. USB Connection:

Connect a USB cable from the PC
to the rear panel USB B port.

RS232 Connection:
Connect an RS232C cable from the
PC to the rear panel RS232 port.

2. Press

System

>Serial Port…[F1]> Serial[F1] to

enter the remote configuration.

3. Set the following RS-232 settings using the

arrow keys:

Baud Rate[F1]:

9600, 19200, 38400, 57600,
115200.

Parity[F2]:

None, Even, Odd, Space,
Mark, Multidrop.

Stop Bit[F3]:

1, 1.5, 2.

Data[F4]:

5, 6, 7, 8

Remote Control Function Check

Functionality
check

Invoke a terminal application such as MTTTY
(Multi-Threaded TTY).

To check the COM port No., see the Device
Manager in the PC.
For WinXP go to;
Control panel → System → Hardware tab.

Run this query command via the terminal after
the instrument has been configured for remote
control (page 79).

*idn?
