GSP-730 User Manual
38
Marker
A Marker shows the frequency and amplitude of a waveform point.
The GSP-730 can activate up to 5 markers or marker pairs
simultaneously.
The marker table and peak table functions help editing and
viewing multiple markers in a single display.
The delta marker function allows you to see the frequency and
amplitude differences between reference markers.
The GSP-730 can automatically move a marker to various locations
including the peak signal, center frequency, and start/stop
frequency. Other marker operations regarding signal peaks are
available in the Peak Search function.
 Activating a Marker → from page 39
 Activate a Delta Marker→ from page 40
 Move Marker Manually→ from page 41
 Move Marker to Preset Locations→ from page 42
 Move Marker to Trace→ from page 43
 Turn All Markers On or Off→ from page 44
 Show Markers in Table→ from page 44
 Peak Search→ from page 46
 Move Marker to Peak→ from page 46
 Move Marker and Peak to Center→ from page 46
 Search for Peaks→ from page 47
 Peak Table→ from page 48
