GSP-730 User Manual

22

Conventions

The following conventions are used throughout the user manual.
Read the conventions below for a basic grasp of how to operate the
GSP-730 menu system and front panel keys.

Soft Menu keys

The F1 to F6 function keys on the right side of
the display correspond directly to the soft-
menu keys on their left.

Soft-menu keys

F1 ~ F6 function keys

dB

Enter

F 1

F 2

F 3

F 4

F 5

F 6

0

BK SP

kHz /

Sec

m

mSec

MHz /

GHz /

Sec

1

4

7

2

5

8

3

6

9

Frequency

Span

Amplitude

Autoset

Marker

Peak

Limit Line

Meas

Search

BW

Trace

Display

Memory

Preset

Hardcopy

System

Hardcopy

Setup

GSP-730

150 kHz 3 GHz

Spectrum Analyzer

RF INPUT 50

+20dBm MAX.

MAX.

DC ±25V

W

Input Parameter
Values


Selecting this type of menu key will allow you
to enter a new value with the numeric keypad
or increment/decrement the value using the
scroll wheel or number pad. See the parameter
input description below for more details.
