GSP-730 User Manual

50

Measurement

This section describes how to use the automatic measurement
modes. The GSP-730 includes the following measurements:

ACPR → from page 51.

OCBW → from page 54.

Channel Analysis Overview

Description

Channel analysis measurement includes ACPR
(adjacent channel power) and OCBW (occupied
bandwidth) measurements.

Parameters

Channel bandwidth

The frequency
bandwidth the target
channel occupies.
Range:
Between 0Hz~3GHz
(0Hz excepted)

Channel Space

The frequency distance
between each main
channel.
Range:
Between 0Hz~3GHz

Adjacent channel
bandwidth 1 & 2

The frequency
bandwidth the adjacent
channels occupy.
Range:
Between 0Hz~3GHz
(0Hz excepted)
