BASIC OPERATION
35
Amplitude Units
Description
The amplitude units can be set from dBm,
dBmV or dBuV.
1. Press
Amplitude
> Units …[F3] to change the
amplitude units.
Units:
dBm, dBmV, dBuV
Scale/Div
Description
Sets the logarithmic units for the vertical
divisions.
Operation
1. Press
Amplitude
> Scale[F2] repeatedly to select the
vertical division units.
Scale Range:
10, 5, 2, 1
Display
Scale
