GETTING STARTED

11

Amplitude

Amplitude

Sets the amplitude reference level,
scale and amplitude units.

Autoset

Autoset

Automatically searches the peak
signal with maximum amplitude
and displays it with appropriate
horizontal and vertical scales.

Marker

Marker

The Marker key is used to
configure the markers, trace
markers as well as other related
functionality.

Peak Search

Peak

Search

Finds each maximum and
minimum peak. Used with the
Marker functions.

Meas

Meas

Configures ACPR and OCBW
measurements.

Limit Line

Limit Line

Sets and tests Pass/Fail limit lines.

BW

BW

Sets the resolution bandwidth.

Trace

Trace

Sets traces and trace related
functions.

Display

Display

The Display key configures the
split-screen windowing mode and
the basic display properties.

Memory

Memory

The memory key is used to save or
recall setup, trace and limit line
data.
