10. OUTLINE
• Measurable Flow Range:
Min. Range
@0.5m/s
Max. Range
@10m/s
15
25
40
50
80
100
150
200
0 to 0.3181
0 to 0.8836
0 to 2.2620
0 to 3.535
0 to 9.048
0 to 14.138
0 to 31.81
0 to 56.55
Size
0 to 6.361
0 to 17.671
0 to 45.23
0 to 70.68
0 to 180.95
0 to 282.74
0 to 636.1
0 to 1,130.9
SI Units (Size : mm, Flowrate : m 3 /h)
Min. Range
@1.6ft/s
Max. Range
@33ft/s
0.5
1
1.5
2
3
4
6
8
0 to 1.0040
0 to 4.016
0 to 9.036
0 to 16.063
0 to 36.15
0 to 64.26
0 to 144.57
0 to 257.01
Size
0 to 20.078
0 to 80.31
0 to 180.70
0 to 321.2
0 to 722.8
0 to 1,285.0
0 to 2,891.3
0 to 5,140
English Units (Size : inch, Flowrate : GPM)
• Fluid Temperature and Pressure
MPa{kgf/cm 2 }(psi)
4{40}(580)
2{20}(290)
1{10}(145)
–0.1{–1}(–14.5)
Pressure
–10
(14)
0
(32)
120(248) Temperature °
C(
°
F)
Diameter 15 (0.5") to 50mm (2")
Diameter 80 (3") to 200mm (8")
This limits show maximum allowable fluid pressure for Flow Tube itself.
Further fluid pressure should also be limitted according to flange rating.
• Reasonable Figures for Thermal Shock for Ceramics
1. Size 15, 25mm (0.5, 1 in)
120(248)
100(212)
60(140)
∆
T
°
C(
°
F)
Increase
Decrease
1(3) 5(15) 10(30) Flow Velocity m/s(ft)
CAUTION
