Counter menu – Watlow EZ-ZONE RM-Scanner-Modul User Manual
Page 68
Watlow EZ-ZONE
®
RMS Module
•
65
•
Chapter 4 Setup Page
RM Scanner Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[`Ctr]
[`Set]
Counter Menu
[``Fn]
[ Fn]
Counter (1 to 24)
Function
Set whether the counter in-
crements or decrements the
count value. Decrementing
0 returns 9,999. Increment-
ing 9,999 returns 0.
[``UP]
Up (1456)
[``dn]
Down (1457)
Up
9196
[offset 40]
0x82 (130)
1 to 0x18
(24)
9
- - - -
30009
uint
RWES
[SFn;A]
[SFn.A]
Counter (1 to 24)
Source Function A
Set the type of function
that will be used for the
counter clock signal.
[nonE]
None (61)
[ALM]
Alarm (6)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out A
(233)
[Ent;b]
Profile Event Out B
(234)
[Ent;C]
Profile Event Out C
(235)
[Ent;d]
Profile Event Out D
(236)
[Ent;E]
Profile Event Out E
(247)
[Ent;F]
Profile Event Out F
(248)
[Ent;g]
Profile Event Out G
(249)
[Ent;h]
Profile Event Out H
(250)
[`FUn]
Function Key (1001)
[`lgC]
Logic (239)
[tMr]
Timer (244)
[`uAr]
Variable (245)
None
9180
[offset 40]
0x82 (130)
1 to 0x18
(24)
1
- - - -
30001
uint
RWES
[`Si;A]
[ Si.A]
Counter (1 to 24)
Source Instance A
Set the instance of the
function selected above.
1 to 250
1
9184
[offset 40]
0x82 (130)
1 to 0x18
(24)
3
- - - -
30003
uint
RWES
[`S2;A]
[ SZ.A]
Counter (1 to 24)
Source Zone A
Set the zone of the function
selected above.
0 to 16
0
9188
[offset 40]
0x82 (130)
1 to 0x18
(24)
5
- - - -
30005
uint
RWES
[sas;A]
[SAS.A]
Counter (1 to 24)
Source Active State A
Set what output state will
indicate on.
[high]
High (37)
[LoW]
Low (53)
[both]
Both (130)
High
9200
[offset 40]
0x82 (130)
1 to 0x18
(24)
0x0B (11)
- - - -
30011
uint
RWES
Note: Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E:
EEPROM
S:
User
Set
