Watlow EZ-ZONE

®

RMS Module

56

Chapter 4 Setup Page

RM Scanner Module

Setup Page

Display

Parameter Name

Description

Range

Default

Modbus

Relative

Address

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Parameter

ID

Data

Type

&

Read/

Write

[`o;Ct]
[ o.Ct]

Output (1 to 4 and 7 to 10)

Control

Set the output control type.

This parameter is only

used with PID control, but

can be set anytime.

[`Ftb]

Fixed Time Base (34)

[`utb]

Variable Time Base

(103)

Fixed

Time

Base

1822
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

2

41

6002

uint
RWES

[`o;tb]
[ o.tb]

Output (1 to 4 and 7 to 10)

Time Base

Set the time base for fixed-

time-base control.

0.1 to 60.0 seconds (solid-

state relay or switched dc)

5.0 to 60.0 seconds (mechani-

cal relay or no-arc power

control)

0.1 sec.

[SSR &

sw dc]

20.0 sec.

[mech,

relay, no-

arc]

1824
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

3

42

6003

float
RWES

[`o;Lo]
[ o.Lo]

Output (1 to 4 and 7 to 10)

Low Power Scale

The power output will nev-

er be less than the value

specified and will represent

the value at which output

scaling begins.

0.0 to 100.0%

0.0%

1836
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

9

43

6009

float
RWES

[`o;hi]
[ o.hi]

Output (1 to 4 and 7 to 10)

High Power Scale

The power output will

never be greater than the

value specified and will

represent the value at

which output scaling stops.

0.0 to 100.0%

100.0%

1838
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

0xA (10)

44

6010

float
RWES

[Alm]
[`Set]
Alarm Menu

[`A;ty]
[ A.ty]

Alarm (1 to 16)

Type

Select whether the alarm

will be off or if it will use

one or two absolute set

points to define an alarm

condition.

[`oFF]

Off (62)

[PR;AL]

Process Alarm (76)

Off

2528

[offset 60]

0x6D

(109)

1 to 0x10

(16)

0xF (15)

20

9015

uint
RWES

[`Sr;A]
[ Sr.A]

Alarm (1 to 16)

Source

Select what will trigger

this alarm.

[none]

None (61)

[``Ai]

Analog Input (142)

[CUrr]

Current (22)

[PWr]

Power, Control Loop

(73)

[`lnr]

Linearization (238)

[mat]

Math (240)

[``Pu]

Process Value (241)

[`uAr]

Variable (245)

[`Cu;r]

Current Read (179)

Analog

Input

2532

[offset 60]

0x6D

(109)

1 to 0x10

(16)

0x11 (17)

21

9017

uint

RWES

[`is;A]
[ iS.A]

Alarm (1 to 16)

Source Instance

Set the instance of the

function selected above.

1 or 250

1

2534

[offset 60]

0x6D

(109)

1 to 0x10

(16)

0x12 (18)

22

9018

uint
RWES

Note: Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .

If there is only one instance of a menu, no submenus will appear .

R: Read

W: Write

E:

EEPROM

S:

User

Set
