Watlow EZ-ZONE

®

RMS Module

55

Chapter 4 Setup Page

RM Scanner Module

Setup Page

Display

Parameter Name

Description

Range

Default

Modbus

Relative

Address

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Parameter

ID

Data

Type

&

Read/

Write

[otpt]
[`Set]
Output Menu

[``Fn]
[ Fn]

Output (1 to 4 and 7 to 10)

Function

Select what function will

drive this output.

[`oFF]

Off (62)

[``ai]

Analog Input

[ALM]

Alarm (6)

[`C;pr]

Cool Power (161)

[`h;pr]

Heat Power (160)

[`CPE]

Compare (230)

[`Ctr]

Counter (231)

[`dio]

Digital I/O (1142)

[Ent;A]

Profile Event Out A

(233)

[Ent;b]

Profile Event Out B

(234)

[Ent;C]

Profile Event Out C

(235)

[Ent;d]

Profile Event Out D

(236)

[Ent;E]

Profile Event Out E

(247)

[Ent;F]

Profile Event Out F

(248)

[Ent;g]

Profile Event Out G

(249)

[Ent;h]

Profile Event Out H

(250)

[`FUn]

Function Key (1001)

[`lnr]

Linearization (238)

[`lgC]

Logic (239)

[mat]

Math (240)

[``Pu]

Process Value (241)

[SoF;1]

Special Function Out-

put 1 (1532)

[SoF;2]

Special Function Out-

put 2 (1533)

[SoF;3]

Special Function Out-

put 3 (1534)

[SoF;4]

Special Function Out-

put 4 (1535)

[tMr]

Timer (244)

[`uAr]

Variable (245)

off

1828
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

5

39

6005

uint
RWES

[``Fi]
[ Fi]

Output (1 to 4 and 7 to 10)

Function Instance

Set the instance of the

function selected above.

1 to 24

1

1830
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

6

40

6006

uint
RWES

[``S2]
[ SZ]

Output (1 to 4 and 7 to 10)

Source Zone A

Set the instance of the

function selected above.

1 to 16

0

1842
[offset 30]

0x6A

(106)

1 to 0x0A

(10)

0x0C (12)

- - - -

6012

uint
RWES

Note: Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .

If there is only one instance of a menu, no submenus will appear .

R: Read

W: Write

E:

EEPROM

S:

User

Set
