Watlow EZ-ZONE

®

RMS Module

36

Chapter 3 Operations Page

RM Scanner Module

Operations Page

Display

Parameter Name

Description

Range

Default

Modbus

Relative

Address

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Parameter

ID

Data

Type

& Read/

Write

[`Su;c]
[ Sv.c]

Process Value (1 to 16)

Source Value C

View the value of Source C.

-1,999.000 to 9,999.000°F

or units

-1,110.556 to 5,555.000°C

- - - -

5214

[offset 70]

0x7E (126)

1 to 0x10

(16)

0x12 (18)

- - - -

26018

float

R

[`Su;d]
[ Sv.d]

Process Value (1 to 16)

Source Value D

View the value of Source D.

-1,999.000 to 9,999.000°F

or units

-1,110.556 to 5,555.000°C

- - - -

5216

[offset 70]

0x7E (126)

1 to 0x10

(16)

0x13 (19)

- - - -

26019

float

R

[`Su;E]
[ Sv.E]

Process Value (1 to 16)

Source Value E

View the value of Source E.

-1,999.000 to 9,999.000°F

or units

-1,110.556 to 5,555.000°C

- - - -

5218

[offset 70]

0x7E (126)

1 to 0x10

(16)

0x14 (20)

- - - -

26020

float

R

[oFSt]
[oFSt]

Process Value (1 to 16)

Offset

Set an offset to be applied

to this function's output.

-1,999.000 to 9,999.000°F

or units

-1,110.556 to 5,555.000°C

0

5224

[offset 70]

0x7E (126)

1 to 0x10

(16)

0x17 (23)

- - - -

26023

float

RWES

[``o;u]
[ o.v]

Process Value (1 to 16)

Output Value

View the value of this func-

tion block's output.

-1,999.000 to 9,999.000°F

or units

-1,110.556 to 5,555.000°C

0.0

5222

[offset 70]

0x7E (126)

1 to 0x10

(16)

0x16 (22)

- - - -

26022

float

R

No Dis-

play

Process Value (1 to 16)

Error

View reported cause for

Linearization output mal-

function.

None (61)

Open (65)

Shorted (127)

Measurement error (140)

Bad calibration data (139)

Ambient error (9)

RTD error (14)

Fail (32)

Math error (1423)

Not sourced (246)

Stale (1617)

None

5232

[offset 70]

0x7E

(126)

1 to 0x10

(16)

0x1B (27)

- - - -

26027

uint

R

[`dio]
[oPEr]
Digital Input/Output Menu

[`do;S]
[ do.S]

Digital Output (1 to 12)

Output State

View the state of this out-

put.

[`off]

Off (62)

[``on]

On (63)

1832

[offset 30]

0x6A (106)

1 to 0x0c

(12)

7

46

6007

uint

R

[`di;S]
[ di.S]

Digital Input (1 to 12)

Input State

View this event input state.

[`off]

Off (62)

[``on]

On (63)

1840

[offset 30]

0x6A (106)

1 to 0x0c

(12)

0xB (11)

- - - -

6011

uint

R

No Dis-

play

Digital Input (1 to 12)

Error

View reported cause for

digital input/output mal-

function.

None (61)

Open (65)

Shorted (127)

Measurement error (140)

Bad calibration data (139)

Ambient error (9)

RTD error (14)

Fail (32)

Math error (1423)

Not sourced (246)

Stale (1617)

None

1848

[offset 30]

0x6A

(106)

1 to 0x0c

(12)

15

- - - -

6015

uint

R

Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .

If there is only one instance of a menu, no submenus will appear .

R: Read

W: Write

E: EEPROM

S: User Set
