Process value menu – Watlow EZ-ZONE RM-Scanner-Modul User Manual
Page 51
Watlow EZ-ZONE
®
RMS Module
•
48
•
Chapter 4 Setup Page
RM Scanner Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[``Pu]
[`Set]
Process Value Menu
[``Fn]
[ Fn]
Process Value (1 to 16)
Function
Set the function that will
be applied to the source or
sources.
[`oFF]
Off (62)
[`S;bA]
Sensor Backup (1201)
[`aug]
Average (1367)
[``C;o]
Crossover (1368)
[`W;b]
Wet Bulb / Dry Bulb
(1369)
[``s;o]
Switch Over (1370)
[diFF]
Differential (1373)
[rAti]
Ratio (1374)
[`add]
Add (1375)
[mul]
Multiply (1376)
[a;dif]
Absolute Difference
(1377)
[min]
Minimum (1378)
[maH]
Maximum (1379)
[root]
Square Root (1380)
[usla]
Vaisala RH Compen-
sation (1648)
[`alt]
Pressure to Altitude
(1649)
Off
5220
[offset 70]
0x7E
(126)
1 to 0x10
(16)
0x15 (21)
64
26021
uint
RWES
[SFn;A]
[SFn.A]
Process Value (1 to 16)
Source Function A
Set the type of function
that will be used for this
source.
[``Ai]
Analog Input (142)
[``Pu]
Process Value (241)
None
5180
[offset 70]
0x7E
(126)
1 to 0x10
(16)
1
- - - -
26001
uint
RWES
[`Si;A]
[ Si.A]
Process Value (1 to 16)
Source Instance A
Set the instance of the
function selected above.
1 to 250
Based on
PV in-
stance
5190
[offset 70]
0x7E
(126)
1 to 0x10
(16)
6
- - - -
26006
uint
RWES
[SFn;b;]
[SFn.b]
Process Value (1 to 16)
Source Function B
Set the type of function
that will be used for this
source.
[nonE]
None (61)
[``Ai]
Analog Input (142)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`uAr]
Variable (245)
None
5182
[offset 70]
0x7D
0x7E
(126)
1 to 0x10
(16)
2
- - - -
26002
uint
RWES
[`Si;B]
[ Si.b]
Process Value (1 to 16)
Source Instance B
Set the instance of the
function selected above.
1 to 250
1
5192
[offset 70]
0x7E
(126)
1 to 0x10
(16)
7
- - - -
26007
uint
RWES
[`S2;B]
[ SZ.b]
Process Value (1 to 16)
Source Zone B
Set the zone of the function
selected above.
0 to 16
0
5202
[offset 70]
0x7E
(126)
1 to 0x10
(16)
0x0C (12))
- - - -
26012
uint
RWES
Note: Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E:
EEPROM
S:
User
Set
