Watlow EZ-ZONE

®

RMS Module

62

Chapter 4 Setup Page

RM Scanner Module

Setup Page

Display

Parameter Name

Description

Range

Default

Modbus

Relative

Address

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Parameter

ID

Data

Type

&

Read/

Write

[`S2;A]
[ SZ.A]

Compare (1 to 24)

Source Zone A

Set the zone of the function

selected above.

0 to 16

0

8228

[offset 40]

0x80 (128)

1 to 0x18

(24)

5

- - - -

28005

uint
RWES

[SFn;B]
[SFn.b]

Compare (1 to 24)

Source Function B

Set the type of function

that will be used for this

source.

[nonE]

None (61)

[``Ai]

Analog Input (142)

[CUrr]

Current (22)

[`C;Pr]

Cool Power, Control

Loop (161)

[`h;Pr]

Heat Power, Control

Loop (160)

[PWr]

Power, Control Loop

(73)

[`Lnr]

Linearization (238)

[MAt]

Math (240)

[``Pu]

Process Value (241)

[`SP;C]

Set Point Closed,

Control Loop (242)

[`SP;o]

Set Point Open, Con-

trol Loop (243)

[`uAr]

Variable (245)

None

8222

[offset 40]

0x80 (128)

1 to 0x18

(24)

2

- - - -

28002

uint
RWES

[`Si;B]
[ Si.b]

Compare (1 to 24)

Source Instance B

Set the instance of the

function selected above.

1 to 250

1

8226

[offset 40]

0x80 (128)

1 to 0x18

(24)

4

- - - -

28004

uint
RWES

[`S2;B]
[ SZ.b]

Compare (1 to 24)

Source Zone B

Set thezone of the function

selected above.

0 to 16

0

8230

[offset 40]

0x80 (128)

1 to 0x18

(24)

6

- - - -

28006

uint
RWES

[`Er;h]
[ Er.h]

Compare (1 to 24)

Error Handling

Select output value and er-

ror output state when com-

pare cannot be processed

[``t;g]

True Good (1476)

[``t;b]

True Bad (1477)

[``F;g]

False Good (1478)

[``F;b]

False Bad (1479)

False Bad 8242

[offset 40]

0x80 (128)

1 to 0x18

(24)

0xC (12)

- - - -

28012

uint
RWES

[tMr]
[`Set]
Timer Menu

[``Fn]
[ Fn]

Timer (1 to 24)

Function

Set how the timer will

function.

[`oFF]

Off (62)

[`on;P]

On Pulse (1471)

[`dEL]

Delay (1472)

[``o;s]

One Shot (1473)

[`rET]

Retentive (1474)

Off

10156

[offset 50]

0x83 (131)

1 to 0x18

(24)

9

131

31009

uint
RWES

Note: Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .

If there is only one instance of a menu, no submenus will appear .

R: Read

W: Write

E:

EEPROM

S:

User

Set
