WAFER-945GSELVDS2
Page 85
ƒ CPU Temperature Limit of OFF [000]
WARNING:
CPU failure can result if this value is set too high because the fan will
turn off before the CPU has been cooled to the normal temperature
range
The fan will turn off if the temperature falls below this value.
ƒ Minimum Value: 0°C
ƒ Maximum Value: 127°C
ƒ CPU Temperature Limit of Start [020]
WARNING:
CPU failure can result if this value is set too high because permanent
damage will be done before it turns on
The fan will start spinning when this temperature is reached.
ƒ Minimum: 0
ƒ Maximum: 127
ƒ Fan Start PWM [070]
The fan initially starts at this speed.
ƒ Minimum: 0
ƒ Maximum: 127
ƒ Slope PWM [0.5 PWM]
Sets how big each increase in the speed of the fan is. Lower settings mean finer tuning of
the fan speed. Higher settings mean bigger jumps in speed as the fan speed changes.
