WAFER-945GSELVDS2
Page 14
Connector Type Label
Digital I/O connector 10-pin header DIO1
Fan connector 3-pin wafer CPU_FAN1
Keyboard and mouse connector 6-pin wafer KB_MS1
LED connector 6-pin header LED_C1
LVDS1 connector 30-pin crimp LVDS1
LVDS1 inverter connector 5-pin wafer INVERTER1
LVDS2 connector 30-pin crimp LVDS2
LVDS2 inverter connector 5-pin wafer INVERTER2
PCIe Mini Card slot PCIe Mini Slot CN4
Power Button 2-pin wafer PWRBTN1
Reset button connector 2-pin header RESET1
Serial ATA (SATA) drive connectors 7-pin SATA SATA1, SATA2
Serial port 10-pin header COM3, COM4
Serial port (RS-232/422/485) 14-pin header COM2
USB 2.0 connector 8-pin header USB01
Table 3-1: Peripheral Interface Connectors
3.2.2 External Interface Panel Connectors
Connector Type Label
Ethernet connector RJ-45 LAN1
RS-232 serial port connector Male DB-9 COM1
Dual USB port USB port USB_C23
USB_C45
VGA port connector 15-pin female VGA1
Table 3-2: Rear Panel Connectors
