WAFER-945GSELVDS2
Page 66
Step 3: Insert the VGA connector. Once the connectors are properly aligned with the
insert the male connector from the VGA screen into the female connector on the
WAFER-945GSELVDS2. See Figure 4-20.
Figure 4-20: VGA Connector
Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA monitor
to the external interface by tightening the two retention screws on either side of
the connector. S te p 0 :
4.10 Heat Sink Enclosure
WARNING:
Never run the WAFER-945GSELVDS2 without the heat sink secured
to the board. The heat sink ensures the system remains cool and does
not need addition heat sinks to cool the system.
