WAFER-945GSELVDS2
Page 20
Pin Description Pin Description
16 A4 41 RESET#
17 A3 42 WAIT#
18 A2 43 INPACK#
19 A1 44 REG#
20 A0 45 BVD2
21 D0 46 BVD1
22 D1 47 D8
23 D2 48 D9
24 IOCS16# 49 D10
25 CD2# 50 GND2
Table 3-7: CF Card Slot Pinouts
3.3.6 Digital I/O Connector
CN Label: DIO1
CN Type: 10-pin header (2x5)
CN Location: See Figure 3-7
CN Pinouts: See Table 3-8
The digital input/output connector is managed through a Super I/O chip. The DIO
connector pins are user programmable.
