WAFER-945GSELVDS2

Page 67

WARNING:

When running the WAFER-945GSELVDS2, do not put the

WAFER-945GSELVDS2 directly on a surface that can not dissipate

system heat, especially the wooden or plastic desk. It is highly

recommended to run the WAFER-945GSELVDS2

Æ on a heat dissipation surface or

Æ using copper pillars to hold the board up from the desk below

When the WAFER-945GSELVDS2 is shipped it is secured to a heat sink with five

retention screws. If the WAFER-945GSELVDS2 must be removed from the heat sink, the

five retention screws must be removed.

Figure 4-21: Heat Sink Retention Screws

4.11 Installing Drivers

To access the driver installation programs, please do the following.
