WAFER-945GSELVDS2
Page 4
Specification WAFER-945GSELVDS2
Memory One 200-pin SO-DIMM socket supports one 400 MHz or
533 MHz 2.0 GB (max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® Type II socket
Super I/O ITE IT8718
Display 18-bit dual-channel LVDS
24-bit dual-channel LVDS
VGA
BIOS AMI
Audio Realtek ALC655 AC'97 audio chip
LAN 1 x Realtek 8111CP PCIe GbE chips
COM 3 x RS-232 serial ports (one external, two internal)
1 x RS-232/422/485 serial port (internal)
USB2.0 6 x USB (four external, two internal)
SATA Two 3.0 Gb/s SATA drives supported
Keyboard/mouse One internal pin-header connector
Expansion One PCIe mini card
Digital I/O 8-bit (4-bit input, 4-bit output)
Power Consumption 2.49 A @ 5 V (1.6 GHz Intel ATOM N270 with 2 GB DDR2)
Temperature 0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating) 5%~95% non-condensing
Dimensions (LxW) 102 mm x 146 mm
Weight (GW/NW) 700 g / 350 g
Table 1-1: Technical Specifications
