5.3.4 CP U Co n fig u ra tio n
Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications
and configure the CPU.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Genuine Intel(R) CPU @ 2.40GHz
CPU Signature
306a5
Microcode Patch 7
Max CPU Speed 2400 MHz
Min CPU Speed 1600 MHz
CPU Speed 2400 MHz
Processor Cores 2
Intel HT Technology Supported
Intel VT-x Technology Supported
Intel SMX Technology Not Supported
64-bit Supported
L1 Data Cache
32 KB x 4
L1 Code Cache 32 KB x 4
L2 Cache 256 KB x 4
L3 Cache 3072 KB
Hyper-threading [Enabled]
Intel Virtualization Technology [Disabled]
Enabled for Windows XP
and Linux (OS optimized
for Hyper-Threading
Technology)and Disabled
for other OS (OS not
optimized for
Hyper-Threading
Technology). When
Disabled only one thread
per enabled core is
enabled.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 6: CPU Configuration
The CPU Configuration menu (BIOS Menu 6) lists the following CPU details:
 Processor Type: Lists the brand name of the CPU being used
 CPU Signature: Lists the CPU signature value.
 Microcode Patch: Lists the microcode patch being used.
 Max CPU Speed: Lists the maximum CPU processing speed.
 Min CPU Speed: Lists the minimum CPU processing speed.
 CPU Speed: Lists the CPU processing speed
 Processor Core: Lists the number of the processor cores
 Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
