IMB-Q770 Mic ro -ATX Mo th e rb o a rd
P a g e 34
3.2.18 P CIe x4 S lo t
CN La b e l: P CIEX4
CN Typ e : PCIe x4 slot
CN Lo c a tio n : See Figure 3-19
The PCIe x4 slot is for PCIe x4 expansion cards.
Figure 3-19: PCIe x4 Slot Locations
3.2.19 P CIe x1 S lo t
CN La b e l: P CIEX1
CN Typ e : PCIe x1 slot
CN Lo c a tio n : See Figure 3-20
The PCIe x1 slot is for PCIe x1 expansion cards.
