IMB-Q770 Mic ro -ATX Mo th e rb o a rd
P a g e 17
3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
ATX power connector 24-pin ATX ATX1
Battery connector battery holder BAT1
CPU power connector 4-pin Molex CPU12V1
DDR3 DIMM slots DDR3 DIMM slot CHA_DIMM1
CHA_DIMM2
CHB_DIMM1
CHB_DIMM2
Debug port connector 4-pin header CN2, CN3
Digital I/O connector 26-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connectors (system) 4-pin wafer SYS_FAN1
Fan connector (system) 3-pin wafer SYS_FAN2
Fan connector (PCH) 3-pin wafer PCH_FAN1
Front panel audio connector 10-pin header FP_AUDIO1
Front panel connector 14-pin header F_PANEL1
FW programming connector 8-pin header CN1
Infrared interface connector 5-pin header IR1
Keyboard/mouse connector 6-pin wafer KB_MS_CN2
PCIe power connector 4-pin Molex PCIE_POWER1
PCI slot PCI slot PCI1
PCIe x16 slot PCIe x16 slot PCIEX16
PCIe x4 slot PCIe x4 slot PCIEX4
PCIe x1 slot PCIe x1 slot PCIEX1
SATA 3Gb/s drive connectors 14-pin SATA connector SATA34, SATA56
