IMB-Q770 Mic ro -ATX Mo th e rb o a rd
P a g e 18
Co n n e c to r Typ e La b e l
SATA 6Gb/s drive connectors 7-pin SATA connector SATA1, SATA2
Serial port connector, RS-422/485 4-pin wafer COM2
Serial port connectors, RS-232 40-pin box header COM3-6,COM7-10
SMBus connector 4-pin wafer SMBUS_1
SPI ROM connector 6-pin header JSPI1
TPM connector 20-pin header TPM1
USB connectors 8-pin header USB3, USB4
Table 3-1: Peripheral Interface Connectors
3.1.3 Exte rn a l In te rfa c e P a n e l Co n n e c to rs
The table below lists the connectors on the external I/O panel.
Co n n e c to r Typ e La b e l
Audio connector Audio jack AUDIO_CV1
DVI and serial port connector 24-pin female, DB-9 male DVI1_DB9
Ethernet and USB 3.0 ports RJ-45, USB 3.0 LAN_USB1,
LAN_USB2
HDMI ports HDMI port HDMI1,HDMI2
USB 2.0 ports USB 2.0 R_USB1
Table 3-2: Rear Panel Connectors
3.2 In te rn a l P e rip h e ra l Co n n e c to rs
The section describes all of the connectors on the IMB-Q770.
3.2.1 ATX P o we r Co n n e c to r
CN La b e l: ATX1
CN Typ e : 24-pin ATX
CN Lo c a tio n : See Figure 3-2
