Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
F81216 Second Super IO Configuration
F81216 Second Super IO Chip F81216 SecondIO
> Serial Port 7 Configuration
> Serial Port 8 Configuration
> Serial Port 9 Configuration
>
Serial Port 10 Configuration
Set Parameters of Serial
Port 7 (COMG)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: Secondary Super IO Configuration
5.3.10.1 S e ria l P o rt n Co n fig u ra tio n
Use the Serial Port n Configuration menu (BIOS Menu 13) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
Serial Port 7 Configuration
Serial Port [Enabled]
Device Settings IO=2B0h; IRQ=11
Change Settings
[Auto]
Device Mode [Serial Port Functi…]
Enable or Disable Serial
Port (COM)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 13: Serial Port n Configuration Menu
