IMB-Q770 Mic ro -ATX Mo th e rb o a rd
P a g e 8
S p e c ific a tio n /Mo d e l IMB-Q770
Display port One DVI-I port
Two HDMI ports
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse One 6-pin wafer for PS/2 KB/MS
TPM One 20-pin header
Front Panel 1 x Front panel connector (power LED, HDD LED, speaker, power
button, reset button)
Front Audio One 10-pin header
SMBUS One 4 pin wafer
I2C One 4 pin wafer
IR One 5 pin header
Fan One 4-pin CPU fan connector
Two 3-pin system fan connectors
Serial Ports One external RS-232 serial port
Eight RS-232 via internal two 40-pin box headers
One RS-422/485 via internal 4-pin wafer
USB ports Four external USB 3.0 ports on rear IO
Two external USB 2.0 ports on rear IO
Four internal USB 2.0 ports by pin header
Serial ATA Two SATA 6Gb/s connectors
Four SATA 3Gb/s connectors
Environmental and Power Specifications
Power Supply ATX power supply
Power Consumption [email protected], [email protected], [email protected], [email protected], [email protected]
(Intel® Core™ i3 3200 3.2GHZ CPU with four 1333MHz 1GB DDR3
memory)
Operating Temperature -10ºC ~ 60ºC
Humidity 5% ~ 95% (non-condensing)
