Disabled D EFAULT Disabled the console redirection function

Enabled Enabled the console redirection function
5.3.13.1 Co n s o le Re d ire c tio n S e ttin g s
The Console Redirection Settings menu (BIOS Menu 19) allows the console redirection
options to be configured. The option is active when Console Redirection option is enabled.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
COM1
Console Redirection Settings
Terminal Type
[ANSI]
Bits per second [115200]
Data Bits [8]
Parity [None]
Stop Bits [1]
Emulation: ANSI:
Extended ASCII char set.
VT100: ASCII char set.
VT100+: Extends VT100 to
support color, function
keys, etc. VT-UTF8: Uses
UTF8 encoding to map
Unicode chars onto 1 or
more bytes.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 19: Console Redirection Settings
 Term in al Typ e [ANSI]
Use the Terminal Type option to specify the remote terminal type.

VT100 The target terminal type is VT100

VT100+ The target terminal type is VT100+

VT-UTF8 The target terminal type is VT-UTF8

ANSI D EFAULT The target terminal type is ANSI
