IMB-Q770 Mic ro -ATX Mo th e rb o a rd
P a g e 99
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control
[Auto Duty-Cycle Mode]
CPU Temperature 1
60
CPU Temperature 2
50
CPU Temperature 3
40
CPU Temperature 4
30
PCH_FAN1 Smart Fan Control
[Auto Duty-Cycle Mode]
PCH Temperature 1
60
PCH Temperature 2
50
PCH Temperature 3
40
PCH Temperature 4
30
SYS_FAN1 Smart Fan Control
[Auto Duty-Cycle Mode]
SYS Temperature 1
60
SYS Temperature 2
50
SYS Temperature 3
40
SYS Temperature 4
30
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2
Previous Values
F3
Optimized Defaults
F4
Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: FAN 1 Configuration
CPU_FAN1 Sm a rt Fan Co n tro l [Au to Du ty-Cycle Mo d e]
Use the CPU_FAN1 Smart Fan Control option to configure the CPU Smart Fan.
Manual Duty
Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
Auto Duty-Cycle
Mode
D
EFAULT
The fan adjusts its speed using Auto by
Duty-Cycle settings
CPU Tem p eratu re n
Use the + or – key to change the fan CPU Temperature n value. Enter a decimal number
between 1 and 100.
PCH_FAN1 Sm a rt Fan Co n tro l [Au to Du ty-Cycle Mo d e]
Use the PCH_FAN1 Smart Fan Control option to configure the PCH Smart Fan.
Manual Duty
Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
