5.2 Ma in
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.5.3
Compliency UEFI 2.3; PI 1.2
Project Version SA45AR11.ROM
Build Date 08/28/2012 14:07:08
Processor Information
Name
IvyBridge
Brand String Genuine Intel(R)CPU
Frequency 240 MHz
Processor ID 306a5
Stepping K0/M0
Number of Processors 2Core(s) / 4Thread(s)
Microcode Revision 7
GT Info GT2 (900 MHz)
IGFX VBIOS Version
2137
Memory RC Version 1.5.0.0
Total Memory 1024 MB (DDR3 1333)
Memory Frequency 1333 MHz
PCH Information
Name
PantherPoint
Stepping 04/C1
TXT Capability of Platform/PCH Unsupported
LAN PHY Revision C0
ME FW Version 8.0.4.1441
ME Firmware SKU 5MB
SPI Clock Frequency
DOFR Support
Supported
Read Status Clock Frequnecy 33 MHz
Write Status Clock Frequnecy 33 MHz
Fast Read Status Clock Frequnecy 33 MHz
System Date
[Wed 08/29/2012]
System Time [19:43:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Date
elements.
----------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
