ZOLL E Series Monitor Defibrillator Rev D User Manual
Page 38
E Series Service Manual
1-28
9650-1450-01 Rev. D
16.6
Decrease the output to 40mA.
Output on the QED 6 analyzer is 40mA or +/- 5mA. Pulse width is
40mS +/-2mS.
o o
16.7
Increase the output to 60mA.
Decrease the rate to 30 ppm.
Pacer rate on QED 6 analyzer is 29-31 ppm
o o
16.8
Increase the rate to 180ppm.
Pacer rate on QED 6 analyzer is 177-183 ppm
o o
16.9
Connect the ECG cable to the E Series and
QED 6 analyzer. Select the ECG at 60 BPM on
the QED 6 analyzer. Decrease the pacer rate
on the unit to 58ppm.
The unit displays ECG at 60 BPM with no stimulus markers.
o o
16.10
Press the Async Pace softkey.
The unit displays ECG at 60 BPM with stimulus markers, and displays the
Async pace message.
o o
16.11
Turn off the QED 6 analyzer. Set Pacer Rate to
100ppm. Press the RECORDER ON button.
The unit displays pace stimulus markers every 15mm +/-1mm.
o o
16.12
Press and hold 4:1 button.
The unit displays pace stimulus markers every 60 mm+/- 1.5 mm.
o o
Record your results on the Maintenance Tests Checklist.
Do this...
Verify that...
Pass/Fail
