background image

E Series Service Manual

1-20

9650-1450-01 Rev. D

11.0 Defibrillator Self Test

WARNING!
SHOCK HAZARD!

TAKE THE NECESSARY PRECAUTIONS TO GUARD AGAINST SHOCK OR INJURY BEFORE YOU START
CONDUCTING THE DEFIBRILLATOR TESTS.

Keep hands and all other objects clear of the multi-function cable connections and defibrillator analyzer when discharging
the defibrillator.

Before you discharge the defibrillator, warn everyone near the equipment to STAND CLEAR.

Caution

Do NOT internally discharge the unit more than 3 times in 1 minute. Note that the rapid repetition of internal discharges at more than 30
Joules may damage the unit.

Tools Needed:

MFC Test Port Connector 1004-0149 with universal cable.

MFC Test Adaptor Connector (Fluke Biomedical Part Number 3010-0378 or equivalent).

QED 6 Defibrillator Analyzer.

ECG Cable.

Stop watch.

Test Setup:

1. Ensure the unit is turned off

2.

Ensure the ECG cable is connected to the unit and analyzer.
