0 synchronized cardioversion test, Synchronized cardioversion test – ZOLL E Series Monitor Defibrillator Rev D User Manual
Page 32
E Series Service Manual
1-22
9650-1450-01 Rev. D
12.0 Synchronized Cardioversion Test
Tools Needed: QED 6 Defibrillator Analyzer.
Test Setup:
1. Connect the universal cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.
2.
Set ECG on analyzer to 60 -120 BPM.
Do this...
Verify that...
Pass/Fail
12.1
12.2
Note: Sync markers display on the monitor. The sync marker appears as a
down arrow over the ECG R-wave peaks on strip chart and display.
o o
12.3
o o
Press LEAD button to select PADS and Size
x1.
Press the SYNC softkey on the defibrillator.
Enter synchronized cardioversion timing test
mode on the defibrillator analyzer.
Sync markers appear on display.
Select 200J, and then press the CHARGE
button. When the SHOCK button lights, press
and hold the SHOCK button.
On the analyzer display, the R-wave to shock delay is less than
60 milliseconds.
Record your results on the Maintenance Tests Checklist.
