ZOLL E Series Monitor Defibrillator Rev D User Manual
Page 119
E Series Service Manual
9650-1450-01 Rev. D
5-9
Table 5-1:
SW1
SW2
SW3
SW4
Control Board Dip Switches Settings
13. Using an exacto knife pry corner of front panel membrane up,
and remove by gently pulling off the membrane.
14. Using an exacto knife pry corner of data entry switch up,
and remove by gently pulling off the membrane.
Manual Advisory
0
0
0
1
AED 0
0
1
1
