E Series Operator’s Guide
A-14
9650-1210-01 Rev. R
Table A-1.
Delivered Energy at Every Defibrillator Settings into a Range of Loads
Figures A-1 through A-20 show the rectilinear biphasic waveforms that are produced when the E Series defibrillator is
discharged into loads of 25, 50, 75, 100, 125, 150, and 175 ohms at each energy setting (200, 150, 120, 100, 85, 70,
50, 30, 20, 15, 10, 9, 8, 7, 6, 5, 4, 3, 2 and 1 joule[s]).
The vertical axis shows the current in amperes (A); the horizontal axis shows the duration in milliseconds (ms).
Selected
Energy
Load
25
50
75
100
125
150
175
Accuracy
1 J
1 J
1 J
1 J
1 J
1 J
1 J
1 J
±3J
2 J
1 J
2 J
3 J
2 J
2 J
2 J
2 J
±3J
3 J
2 J
3 J
4 J
4 J
3 J
3 J
3 J
±3J
4 J
3 J
4 J
5 J
5 J
5 J
4 J
4 J
±3J
5 J
4 J
5 J
6 J
6 J
6 J
5 J
5 J
±3J
6 J
4 J
6 J
8 J
7 J
7 J
6 J
6 J
±3J
7 J
5 J
7 J
9 J
9 J
8 J
8 J
7 J
±3J
8 J
6 J
8 J
10 J
10 J
9 J
9 J
8 J
±3J
9 J
7J
9 J
11 J
11 J
10 J
10 J
9 J
±3J
10 J
7 J
10 J
13 J
12 J
12 J
11 J
10 J
±3J
15 J
11 J
15 J
19 J
19 J
17 J
16 J
15 J
±3J
20 J
15 J
19 J
25 J
25 J
23 J
22 J
20 J
±3J
30 J
22 J
29 J
38 J
37 J
35 J
32 J
30 J
±15%
50 J
37 J
48 J
63 J
62 J
58 J
54 J
50 J
±15%
70 J
53 J
69 J
90 J
89 J
83 J
77 J
71 J
±15%
85 J
65 J
86 J
112 J
110 J
103 J
96 J
89 J
±15%
100 J
74 J
97 J
126 J
125 J
116 J
108 J
100 J
±15%
120 J
88 J
116 J
151 J
149 J
139 J
129 J
120 J
±15%
150 J
110 J
145 J
188 J
186 J
174 J
161 J
150 J
±15%
200 J
146 J
214 J
238 J
234 J
213 J
195 J
179 J
±15%
