E Series Service Manual
9650-1450-01 Rev. D
1-23
13.0 Shock Test
Tools Needed: QED 6 Defibrillator Analyzer, Stop Watch.
Test Setup:
1. Connect the universal cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.
2.
Ensure that a fully charged battery is installed in the unit.
Note:
If your E Series AED does not have manual override capability, do not perform this test.
Do this...
Verify that...
Pass/Fail/NA
13.1
Turn the selector switch to DEFIB mode.
(For AED units, turn the selector switch to ON
and select Manual mode.)
13.2
Press the ENERGY SELECT down arrow until
5J displays.
The unit displays DEFIB 5J SEL.
o o o
13.3
Press the CHARGE button. Wait for the
SHOCK button to illuminate.
The unit displays DEFIB 5J RDY.
o o o
13.4
Press the SHOCK button.
The unit discharges 3J-5J into the simulator.
Note: The displayed rhythm may change shape for 30 seconds before it
returns to an original rhythm. This is caused by the operation of the
adaptive bandwidth defibrillator recovery circuit.)\
o o o
13.5
Press the ENERGY SELECT up arrow until 50J
displays.
Energy delivered is within + /- 15% or 2J of setting which ever is greater.
o o o
13.6
Press the ENERGY SELECT up arrow until the
unit displays 50J.
The unit displays the message, DEFIB 50J SEL.
o o o
13.7
Press the CHARGE button. Wait for the
SHOCK button to illuminate.
The unit displays the message, DEFIB 50J RDY.
o o o
13.8
Press the SHOCK button.
The unit discharges 41J-55J into the simulator.
o o o
13.9
Press the ENERGY SELECT up arrow until the
unit displays 100J.
The unit displays the message, DEFIB 100J SEL
o o o
