Part No. Description Qty
MMA-570 RECOMMENDED SPARE PARTS (Cont.)
Select Option Below - Fluid Tip (Cont.)
A11240-04 Fluid Tip, .047/1.2mm Opening
0-1
A11240-05 Fluid Tip, .062/1.57mm Opening 0-1
A11240-06 Fluid Tip, .039/1.0mm Opening 0-1
Select Option Below- Bell Cup Assembly W/Splash Plate
A13114-00 55mm Serrated, Titanium (TISF) 1
A13114-01 55mm Non-Serrated, Titanium (TIF) 1
A11968-00 30mm Titanium Serrated (TIS) 1
A11968-01 30mm Aluminum Serrated (ALS) 1
A12900-00 65mm Titaniun Serrated (TISF) 1
A12900-01 65mm Titanium Non-Serrated (TIF) 1
A12900-02 65mm Titanium Serrated W/Long Life Splash Plate (TISF) 1
A12900-03 65mm Titanium Non-Serrated W/Long Life Splash Plate 1
A12900-04 65mm Aluminum Serrated W/Plastic Splash Plate 1
A12900-05 65mm Aluminum Non-Serrated W/Long Life Splash Plate 1
A12900-06 65mm Aluminum Serrated Black Coated W/Plastic Splash Plate 1
A12900-07 65mm Aluminum Non-Serrated Black Coated W/Plastic Splash Plate 1
Select Option Below- Bell Cup Only
A13541-00
65mm Aluminum Serrated Black Coated (ALSF) 1
A13541-01 65mm Aluminum Non-Serrated Black Coated (ALF) 1
A11964-00 30mm Titanium Serrated (TIS) 1
A11964-01 30mm Aluminum Serrated (ALS) 1
A12886-00 65mm Titanium Serrated (TISF) 1
A12886-01 65mm Titanium Non-Serrated (TIF) 1
A12886-02 65mm Aluminum Serrated (ALS) 1
A12886-03 65mm Aluminum Non-Serrated (ALF) 1
A13113-00 55mm Titanium Serrated (TISF) 1
A13113-01 55mm Titanium Non-Serrated (TIF) 1
Select Option Below- Splash Plate Only
A11269-00
For 55mm Bell Cups (White Colr) 1-2
A11954-00 for 30mm Bell Cups (White Color) 1-2
A12071-00 For 65mm Bell Cups (Black Color) 1-2
A13004-00 For 65mm Bell Cups (Long Life- Titanium Top) 1-2
Select Option Below - Shaping Air Kit A12874-03 (30mm)
A11967-00 Outer Shroud
0-1
A12873-00 Shaping Air Ring, 55mm 0-1
MMA-570 Direct/Indirect Charge - Parts Identification
Ransburg
LN-9279-13 95
