Page 19
55/65MM MMA-570 INDIRECT TOOL
POINT DIEMENSIONS (DUAL FLEX)
6-Inches (152mm) 18.91-Inches (480.3mm)
8-Inches (203mm)
20.91-Inches (531.1mm)
10-Inches (254mm) 22.91-Inches (581.9mm)
12-Inches (305mm) 24.91-Inches (632.7mm)
Weight: 12.12 lbs. (5.5 Kg)
TD
X
MMA-570 TOOL CENTER POINT DIMENSIONS
(55 or 65mm Dual Flex)
“X”
12.91 [327.9]
11.98 [304.4]
5.61 [142.4] COG
4.50
[114.2]
3.90
[99.0]
.43
[11.0]
4.50
[114.3]
3.56
[90.4]
.03 [.6]
COG
9.07
[230.5]
MMA-570 Direct/Indirect Charge - Introduction
Ransburg
LN-9279-13
16
