* Customer must verify spindle part number located on outer housing, see page 12.
00 NONE NONE
01 A12895-01 SPINDLE ASSEMBLY, SILVER SHAFT
04 A12895-04 SPINDLE ASSEMBLY, BLACK SHAFT
TABLE D - SPINDLE SELECTION
Dash No. *Description D
01 A12874-03 30MM (DIRECT CHARGE)
02 A12874-04 30MM WITH REPULSION RING (DIRECT CHARGE)
03 A12874-05 65MM MONO FLEX (DIRECT CHARGE)
04 A12874-06 65MM MONO FLEX WITH REPULSION RING (DIRECT CHARGE)
05 A12874-07 65MM MONO FLEX (INDIRECT CHARGE)
06 A12874-08 65MM DUAL FLEX (DIRECT CHARGE)
07 A12874-09 65MM DUAL FLEX WITH REPULSION RING (DIRECT CHARGE)
08 A12874-10 65MM DUAL FLEX (INDIRECT CHARGE)
09 A12874-11 65MM DUAL FLEX, TFE SHROUD (INDIRECT CHARGE)
10 A12874-12 55MM DUAL FLEX (DIRECT CHARGE)
11 A12874-13 55MM DUAL FLEX (INDIRECT CHARGE)
TABLE C - SHAPING AIR KIT
Dash No. Description C
00 NONE NONE NONE NONE
01 A12079-00 A11343-02 79001-45 FOR USE AT SEA LEVEL
02 A12079-00 A11343-03 79001-45 FOR USE ABOVE 5000 FT. SEA LEVEL
00 NONE NONE
01 A12090-02 FOR ALL BELL CUPS AND SHAPE AIR CONFIGURATIONS
TABLE E - HIGH VOLTAGE RING AND ELECTRODE ASSEMBLY
Dash No. Description E F G
TABLE F - TOOL KIT
Dash No. *Description H
MMA-570 Direct/Indirect Charge - Parts Identification
