Page 29
DIRECT CHARGE VALVE SCHEMATIC
INDIRECT CHARGE VALVE SCHEMATIC
PAINT VALVE
DUMP VALVE
TO PAINT WASTE TANK
BELL CUP
EXTERIOR CUP WASH
INTERNAL CUP WASH
FLUID TUBE
PAINT SUPPLY
VALVE PLUG
CUP WASH
SOLVENT VALVE
SOLVENT OUT
SOLVENT IN
PAINT VALVE
DUMP VALVE
TO PAINT WASTE TANK
BELL CUP
EXTERIOR CUP WASH
INTERNAL CUP WASH
FLUID TUBE
CUP WASH
SOLVENT VALVE
SOLVENT OUT
SOLVENT IN
EXTERNAL CUP WASH PATH
THROUGH ATOMIZER BODY
EXTERNAL CUP WASH PATH
THROUGH ATOMIZER BODY
PAINT SUPPLY
CUP WASH AIR
CUP WASH
AIR VALVE
MMA-570 Direct/Indirect Charge - Introduction
Ransburg
LN-9279-13
26
