O-RINGS

All O-rings in this atomizer are solvent proof

except those on the air bearing spindle. These

O-rings must not be soaked in solvent; if these

are exposed or soaked in solvent, they must

be replaced. These O-rings are engineered to

provide a fit between the air bearing spindle and

it’s mating parts to reduce or eliminate harmonic

resonance (vibration).
Some O-rings are encapsulated. These O-rings

have a limited amount of stretch and will not return

to their original diameters if over stretched. These

O-rings are subject to being distorted more easily

than rubber O-rings, so it is important that they

be sufficiently lubricated when mating parts are

installed onto them. They also will take a square

set over time and should be replaced periodically

if mating parts are removed repeatedly or if a new

mating part is installed onto them.
Any O-ring that is cracked, nicked, or distorted

must be replaced.
A suitable lubricant is food grade petroleum jelly

or A11545-00 Petrolatum Jell.

CLEANING PROCEDURES

In addition to the above Warning, which relates

to potential safety hazards, the following infor-

mation must be observed to prevent damage to

the equipment.

Internal Fluid Path Purge Cleaning

Cleaning the incoming paint line (from paint sup-

ply source such as color manifold through the

fluid manifold and bell assembly): Turn off the

high voltage and turn on the color stack trigger

valve for solvent supply. With the bell spinning,

flush cleaving solvent through the incoming paint

line and through the manifold passages, and out

through the dump valve. Use restricted bell wash

solvent to clean the fluid tube and bell cup. The

spinning bell will atomize the solvent and clean

out the bell passages. If desired, open the dump

valve to flush through the dump line for a faster

and contained system flush.

MAINTENANCE

W A R N I N G

!

C A U T I O N

!

†

Electrical shock and fire hazards can exist

during maintenance. MicroPak supply must

be turned off before entering the spray area

and performing any maintenance procedures

on the atomizer. Spray booth fans should

remain on while cleaning with solvents.

†

Never touch the atomizer bell while it

is spinning. The front edge of the bell can

easily cut into human skin or cut through

gloves and other materials. Be sure the

atomizer bell has stopped spinning be-

fore attempting to touch it. Approximate

time for the bell to stop spinning after turn-

ing off turbine drive air is three minutes.

†

Ensure high voltage is off during any man-

ual cleaning procedure.

†

DO NOT immerse the MMA-570 turbine in

solvent or other liquids. Turbine components

will be damaged and warranty will be voided.

†

Bearing air must be on during all cleaning pro-

cedures to protect the air bearing components.

C A U T I O N

!

†

The maximum flow rate of 800 cc/min.

must not be exceeded during a flush routine.

Use of an in-line fluid restrictor is recom-

mended.

External Atomizer Surface Cleaning

Verify that the high voltage is turned off.

All external surfaces may be cleaned using a

mild solvent and lint free rags to hand wipe the

MMA-570 Direct/Indirect Charge - Maintenance

Ransburg

LN-9279-13
