Page 24
MMA-570 TOOL POINT CENTER DIMENSIONS
(65mm Mono Flex)
65MM MMA-570 DIRECT TOOL POINT
DIEMENSIONS (MONO FLEX)
6-Inches (152mm) 18.91-Inches (480.3mm)
8-Inches (203mm)
20.91-Inches (531.1mm)
10-Inches (254mm) 22.91-Inches (581.9mm)
12-Inches (305mm) 24.91-Inches (632.7mm)
Weight:
10.28 lbs. (4.5 Kg)
TD
X
MMA-570 Direct/Indirect Charge - Introduction
Ransburg
LN-9279-13
21
