Ransburg, Mma-570 direct/indirect charge - introduction – Ransburg MMA-570 Direct_Ind Charge Atomizer A13366 User Manual
Page 26
MMA-570 TOOL CENTER POINT DIMENSIONS
(65mm Mono Flex W/Adapter)
65MM MMA-570 DIRECT TOOL POINT
DIMENSIONS (MONO FLEX WITH ADAPTER)
6-Inches (152mm)
23.28-Inches (591.4mm)
18.08-Inches (459.3mm)
8-Inches (203mm)
25.28-Inches (642.2mm)
19.81-Inches (503.3mm)
10-Inches (254mm)
27.28-Inches (693.0mm)
21.55-Inches (547.3mm)
12-Inches (305mm)
29.28-Inches (743.8mm)
23.28-Inches (591.3mm)
Weight: 16.46 lbs. (7.5 Kg)
TD
X
Y
MMA-570 Direct/Indirect Charge - Introduction
Ransburg
LN-9279-13
23
