C A U T I O N

!

Normally, for painting application, the process

sequence should always be:

• Bearing air on (always On)
• Turbine air on
• Turbine speed to application speed
• Shaping air on
• Start fluid flow off part
• Voltage on

After spraying the object, the sequence should be:

• Voltage lowered to 30-50 kV
• Fluid off
• Shaping air to setback volume
• Turbine speed to set back speed (30,000

rpm recommended)

Recommended sample cup flush sequence is as

follows (voltage must be off) (internal and external

cup wash):

1. Turbine speed set to 25,000-30,000 rpm.
2. Set to 350-450 slpm (12.4-15.9 SCFM).
3. Point atomizer at a grounded object such

as a booth grate.

4. Maintain solvent pressure of 100-150 psi

(689-1,034 kPa). Maintain air push pres-

sure at 80-100 psi (552-689 kPa).

5. Use an alternating trigger sequence of sol-

vent/air to create a chopping effect. Always

ensure that the last step in the sequence is

an air push.

A typical sequence is .2 seconds solvent, 1.0 sec-

ond air push, 1.7 seconds solvent and 2.0 seconds

final air push. This sequence may be modified for

other paints and applications.

6. It is recommended that an in-line fluid filter

be installed to ensure that no foreign debris

enters the fluid tip or the external wash

nozzle.

The MMA-570 is versatile in processing the fin-

ish of a component. It can be setup as shown in

“Typical Paint Sequence” figure.

Recommended sample cup purge sequence is as

follows (voltage must be off) (internal cup cleaning):

1. Turbine speed set to 25,000-30,000 rpm.
2. Increase shaping air to 350-450 slpm

(12.4-15.9 SCFM).

3. Paint atomizer at booth grate or insert into

bell cleaning station.

4. Maintain solvent pressure of 100-150 (689-

1,034 kPa). Maintain air push pressure at

80-100 psi (552-689 kPa).

5. Use an alternating trigger sequence of sol-

vent/air to create a chopping effect. Always

ensure that the last step in the sequence is

an air push.

6. A typical sequence is .3 seconds solvent,

1.7 seconds air push, repeat 3 times. This

sequence may be modified for other paint

and applications.

†

It is recommended to leave bearing air

on, unless the applicator is being serviced or

removed for service.

GENERAL OPERTING SEQUENCE

- DIRECT / INDIRECT CHARGE

MMA-570 Direct/Indirect Charge - Operation

Ransburg

LN-9279-13

44
