MMA-570 TOOL CENTER POINT DIMENSIONS
(65mm Mono Flex)
65MM MMA-570 INDIRECT TOOL
POINT DIEMENSIONS (MONO FLEX)
6-Inches (152mm) 18.91-Inches (480.3mm)
8-Inches (203mm)
20.91-Inches (531.1mm)
10-Inches (254mm) 22.91-Inches (581.9mm)
12-Inches (305mm) 24.91-Inches (632.7mm)
Weight: 13.97 lbs. (6.3 Kg)
