Ransburg MMA-570 Direct_Ind Charge Atomizer A13366 - Manual (Page 96)

A11555-00 Air Stud, Small 2-3
A11556-00 Air Stud, Medium 2-3
A11557-00 Air Stud, Large 2-3
78265-00 Fitting, 6mm, AN 1-2
78269-00 Ferrule, Front, 6mm 1-2
78270-00 Ferrule, Back, 6mm 1-2
78273-00 Nut, 6mm 0-1
77762-01 Collet, 6mm 2-4
77516-04 Collet, 4mm 2-4
77762-04 Collet, 8mm 2-4
77762-02 Collet, 10mm 1-2
77536-04 Tubing, 5/32” OD X .106” ID, Blue Nylon --
77536-03 Tubing, 5/32” OD X .106” ID, Green Nylon --
77536-06 Tube, 4mm OD X 2.7mm ID, Gray/Silver Nylon --
77536-07 Tube, 4mm OD X 2.7mm ID, Yellow Nylon --
77536-08 Tube, 4mm OD X 2.7mm ID, Orange Nylon --
A10839-06 Tube, 10mm OD X 8mm ID, Green --
A10893-04 Tube, 8mm OD X 6mm ID, Gray Nylon --
A10893-07 Tube, 8mm OD X 6mm ID, Blue Nylon --
A10840-08 Tube, 6mm OD X 4mm ID, Yellow Nylon --
A10840-09 Tube, 6mm OD X 4mm ID, Orange Nylon --
A10840-06 Tube, 6mm OD X 4mm ID, Green Nylon --
A10841-01 Tubing, 10mm OD X 8mm ID, PFA, --
A10841-02 Tubing, 8mm OD X 6mm ID, PFA, --
A10841-03 Tubing, 6mm OD X 4mm ID, PFA, --
78268-00 Screw, Socket Head Cap, 10mm X 1.5” 4-6
A12409-XX Fiber Optic Cable 4-6
A10560-XX High Voltage Cable Assembly 1
78375-XX Cable, High Voltage Ground 1
A11283-00 Solvent Circulation Line Assembly 1
A11531-00 Fiber Optic Transmitter Assembly 1
78278-00 Nut, Fiber Optic Tensioning 0-1
A12079-00 High Voltage Ring 0-1
A11318-00 Locknut, High Voltage Tube 0-1
A11317-00 Bent Tube 0-1
A12895-XX Spindle Assembly 0-1
A11245-00 Fluid Tube Assembly 0-1
Part No. Description Qty
MMA-570 RECOMMENDED SPARE PARTS
MMA-570 Direct/Indirect Charge - Parts Identification
Ransburg
LN-9279-13 93
